Display
Screen Size
21.5″
Contrast Ratio
600:1
Response Time
1.2 ms
Resolution
1920 x 1080
Brightness
200 nit
Viewing Angle
90° / 65°
Aspect Ratio
16:9
Color Depth
16.7 million colors
Menu Control
LCD
Buttons on bezel
Connections
BNC Video Input
1 BNC Input (CVBS)
BNC Video Output
1 BNC Output (CVBS)
VGA Video Input
1 VGA Input
HDMI Video Input
1 HDMI Input
Power Requirements
Type
DC24V – 1A
Power Consumption
25 Watts
Physical
Product Dimensions without Stand
20.67″ (W) x 12.6″ (H) x 2.14″ (D)
525.21mm (W) x 320.21mm (H) x 54.4mm (D)
Product Weight without Stand
8.37 lbs (3.8 kg)
Materials
Bezel
Plastic
Mounting
Mounting Hole Pattern
VESA 100
Environmental
Operating Temperature
32° to 122° F (0° to 50° C)
Operating Humidity
0% to 90% RH
Standards
FCC
Part 15B, Class B
RoHS
Compliant
TÜV SÜD
Compliant
What’s Included
DC24V Pigtail Connector
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
